Stick 2
| 65° | Ø | xw | ww | nw | cw |
|---|---|---|---|---|---|
| 0,5m | 470 | 1520 lx | 1620 lx | 1780 lx | 1960 lx |
| 1,0m | 940 | 380 lx | 405 lx | 445 lx | 490 lx |
| 1,5m | 1410 | 169 lx | 180 lx | 198 lx | 218 lx |
| 2,0m | 1880 | 95 lx | 101 lx | 111 lx | 123 lx |
| 2,5m | 2350 | 61 lx | 65 lx | 71 lx | 78 lx |
Stick 2
Pluggable linear luminaire 24V DC LED Stick 2 200mm 24 LED 1,6W nw
Description:
Pluggable LED Stick without dark zones in an aluminum profile, light color neutral white approx. 4000K, easy installation with attached clips, simply connect the supply cable and connect the LED Sticks up to 2.4m or use one Stick SE (with lateral feeder) for infinite light rows, optional accessories: dimmable transformer with radio remote control or 1-10V dimmer, glass edge profile for lateral light supply of glass panes, push-button switch, cover and milled profile for complete installation in woodConnection:
LED-Trafo DC 24VLife:
L70/B10 >= 60.000hEnergy efficiency:
LED 98 lm/W; luminaire: 600 lm/m (75 lm/W)Colour rendering:
Ra/CRI >= 95Special features:
- maximum 20W or 2,4m per supply cable
- without dark zones
- LED Stick with lateral feeder for continuous strip lighting
Further Information:
See FAQ
Order number:
20202122205
limited availability
available versions
Choose from the options below. The currently selected one is highlighted in color.
| article number | description | colour rendering | light colour |
|---|---|---|---|
| 20202122304 | LED Stick 2 300mm 36 LED 2,4W xw | Ra/CRI >= 95 | 2700K extra warm white |
| 20202122202 | LED Stick 2 200mm 24 LED 1,6W ww | Ra/CRI >= 95 | 3000K warm white |
| 20202122302 | LED Stick 2 300mm 36 LED 2,4W ww | Ra/CRI >= 95 | 3000K warm white |
| 20202122322 | LED Stick 2 300mm 36 LED 2,4W ww SE | Ra/CRI >= 95 | 3000K warm white |
| 20202122205 | LED Stick 2 200mm 24 LED 1,6W nw | Ra/CRI >= 95 | 4000K neutral white |
| 20202122305 | LED Stick 2 300mm 36 LED 2,4W nw | Ra/CRI >= 95 | 4000K neutral white |
| 20202122325 | LED Stick 2 300mm 36 LED 2,4W nw SE | Ra/CRI >= 95 | 4000K neutral white |
| 20202122201 | LED Stick 2 200mm 24 LED 1,6W cw | Ra/CRI >= 85 | 5000K cool white |
| 20202122301 | LED Stick 2 300mm 36 LED 2,4W cw | Ra/CRI >= 85 | 5000K cool white |
